BIOS
NITX-315/NITX-315-ET Installation and Use (6806800L71D)
99
5.5.2.5
DXE Beep Codes
5.5.2.6
CPU Exception Status Codess
0xD8
Invalid password
0xD9
Error loading Boot Option (LoadImage returned error)
0xDA
Boot Option is failed (StartImage returned error)
0xDB
Flash update is failed
0xDC
Reset protocol is not available
Table 5-30 DXE Status Codes (continued)
Status Code
Description
Table 5-31 DXE Beep Codes
# of Beeps
Description
4
Some of the Architectural Protocols are not available
5
No Console Output Devices are found
5
No Console Input Devices are found
1
Invalid password
6
Flash update is failed
7
Reset protocol is not available
Table 5-32 CPU Exception Status Codes
Status Code
Description
0x00
Divide error
0x01
CPU Debug exception
0x02
Non maskable hardware Interrupt occurred
0x03
INT 3 breakpoint
