Hardware Preparation and Installation
NITX-315/NITX-315-ET Installation and Use (6806800L71D)
30
2.1.2
Thermal Requirements
Table 2-2 Environmental Requirements of NITX-315-ET
Requirement
Operating
Non-Operating
Cooling Method
Fanless
Temp Cycle Class
-40-+85C:500cyc
Temperature
-20°C—70°C
-40-+85C
Humidity
10-90% (non-condensing)
Vibration
.01 g^2/Hz @ 5-500Hz
Shock
20g 11ms sine or saw
Altitude
-60 - 4000 m ASL
Table 2-3 Critical temperature Spots for NITX-315 and NITX-315-ET
Component Identifier
Heat Dissipation Power (W)
Maximum Allowable
Temperature (°C)
CPU:
Commercial Temperature:
Atom E640
Extended Temperature:
Atom E640T
3.6
(both Commercial
Temperature and Extended
Temperature)
90 (Tj of Commercial
Temperature )
110 (Tj of Extended
Temperature)
IOH: EG20T
1.55
115.7 (Tj)
Memory SDRAM
1GB
1
85 (Tc of Commercial version)
95 (Tc of Extended
Temperature version)
