15 battery header (p17), 16 front panel header (p19), Table 3-16 – Artesyn NITX-315/NITX-315-ET Installation and Use (August 2014) User Manual
Page 50: Battery header pin definition, Table 3-17, Front panel header pin definition, Controls, leds, and connectors
Controls, LEDs, and Connectors
NITX-315/NITX-315-ET Installation and Use (6806800L71D)
50
3.2.15 Battery Header (P17)
3.2.16 Front Panel Header (P19)
8
DAT2
9
CD#
10
WP
Table 3-15 SDIO Header Pin Definition (continued)
Pin
Signal
Table 3-16 Battery Header Pin Definition
Pin
Signal
1
VBAT
2
GND
Table 3-17 Front Panel Header Pin Definition
Pin
Signal
1
HD_LED
2
POWER_LED
3
HD_LED_N
4
GND
5
GND
6
PWRBTN
7
RESET
8
GND
9
Dummy
