BIOS
NITX-315/NITX-315-ET Installation and Use (6806800L71D) 84
vBIOS Version 2032
IEGD Driver Version N/A
MSAC Mode Select Select the size of the graphics memory aperture and untrusted
space. Used by the Integrated Graphics Device. Item: Enabled,
512MB; Enabled, 256MB; Enabled, 128MB. Default is "Enabled,
256MB".
IGD - Boot Type Select the Video Device which will be activated during POST. This has
no effect if external graphics present. Items: VBIOS Default, CRT,
LVDS, CRT+LVDS. Default is VBIOS Default
Boot Display Configuration Boot Display Configuration, see Table 5-18 on page 84
This item only shows with LVDS version BIOS, by default, this item is
not shown.
Table 5-18 Boot Display Configuration
Field Description
Boot Display Configuration
Display Device Support display device list: VGA CH7317, 800x600 AUO G104SN03,
1024x768 CHI MEI G121X1-L04. The default is the VGA CH7317.
VBIOS supports VESA mode, it could not handle mode 0x123 for display to a non-standard
mode such as 1650x1050.
Table 5-19 South Bridge Chipset Configuration
Field Description
South Bridge Chipset Configuration
USB MUX Switch Configure the USB MUX setting, switch to Mini-PCIE or USB header.
Items: Mini-PCIE Slot, USB Header. Default is USB Header.
Table 5-17 North Bridge Chipset Configuration (continued)
Field Description
