Chapter 1
NITX-315/NITX-315-ET Installation and Use (6806800L71D) 19
Introduction
1.1 Overview
NITX-315/NITX-315-ET is a highly integrated Small Form Factor Nano-ITX board based on the
Queensbay Platform, including the Tunnel Creek processor and Topcliff IOH. The NITX-
315/NITX-315-ET incorporates the standard processor, memory, graphics and I/O
functionality, as is common as a small form factor PC motherboard. The NITX-315/NITX-315-
ET operates with or without a local display. Standard PC expansion ports are also available on
the rear panel along with additional USB ports, SATA and LVDS via headers on the board as well
as a single PCIExpress expansion slot. Because the NITX-315/NITX-315-ET is based on the
latest Intel Queensbay platform, it has a long product life cycle, lower power consumption and
suitable for fanless applications. NITX-315/NITX-315-ET performs well within extended
temperature ranges for more rugged commercial applications. NITX-315-ET is designed to
meet -20 - 70 °C ambient temperature requirement.
Table 1-1 Key Features of the NITX-315
Function Features
Processor  Intel Tunnel Creek processor E640 1.0GHz
 Single channel memory controller supporting DDR2 800 MT/s
memory down
 Both LVDS up to 1280x768 @ 60Hz and SDVO output up to
1280x1024 @ 85Hz output support
 Four x1 lane PCI Express root ports supporting the PCI Express Base
Specification, Revision 1.0a
 Implements an LPC interface as described in the LPC1.1
specification
 SMBus Host Controller based on Version 1.0 support
 Serial Peripheral Interface
 Integrated WDT
IOH  Intel Topcliff IOH
BIOS Device  One 4MB SPI boot device
Memory  Supports 1GB 32-bit DDR2 800 MHz non-ECC memory down on
NITX-315
eUSB Flash  An optional eUSB flash on one 2x5 header on board
PCI-E  One PCI-E x1 slot
 One Mini PCI-E socket
