Controls, LEDs, and Connectors
NITX-315/NITX-315-ET Installation and Use (6806800L71D)
45
3.2.5
USB client header (P18)
3.2.6
CPU JTAG header (P20) - Optional
3.2.7
USB Header (P6)
Table 3-6 USB Client Header Pin Definition
Pin
Signal
1
USB power detect
2
D-
3
D+
4
GND
Table 3-7 CPU JTAG Header Pin Definition
Pin
Signal
1
XDP_TDI
2
CPU_TDI
3
INT_TDI
4
CPU_TDO
5
IO_TDO
6
XDP_TDO
Table 3-8 USB Header Pin Definition
Pin
Signal
1
USB0_PWR
