Controls, LEDs, and Connectors
NITX-315/NITX-315-ET Installation and Use (6806800L71D)
48
3.2.11 SPI Program Header (P21)
3.2.12 Full Wire RS232 Header (P7)
Table 3-12 SPI Program Header Pin Definition
Pin
Signal
1
V3V3_POWER
2
GND
3
SPI_CS
4
SPI_CLK
5
SPI_MISO
6
SPI_MOSI
7
NC
8
NC
Table 3-13 Full Wire RS232 Header Pin Definition
Pin
Signal
1
COM1A_DCD
2
COM1A_RXD
3
COM1A_TXD
4
COM1A_DTR
5
GND
6
COM1A_DSR
7
COM1A_RTS
8
COM1A_CTS
9
COM1A_RI-
