Controls, LEDs, and Connectors

NITX-315/NITX-315-ET Installation and Use (6806800L71D)

44

3.2.3

LVDS Backlight Header (P23)

3.2.4

LVDS Power Header (P5)

Table 3-3 LVDS Inverter Header Pin Definition

Pin

Signal

1

VCC12V

2

LVDS_BKLT_EN

3

GND

4

LCD_BKL_ADJ

5

VCC5V

Table 3-4 LVDS Power Connector Pin Definition

Pin

Signal

1

D33VS

2

VCC_LVDS_SEL

3

D50VS

Table 3-5 LVDS Power Jumper Pin Definition

Jumper setting
(Jumper:P5)

Configuration

P5 (1-2)

Using 3.3V to power the
LVDS panel

P5 (2-3)

Using 5V to power the
LVDS panel
