Controls, LEDs and Connectors

ATCA-F120 Installation and Use (6806800D06J)

51

The connector pinout is as follows.

Table 3-1 Serial Connector Pinout

Pin

Signal

1

n.c.

2

RXD

3

TXD

4

n.c.

5

GND

6

n.c.

7

n.c.

8

n.c.

9

n.c.
