Audio Synch
(ms) audio synch offset in milliseconds (ms) with an available range of
-800 ms to +800 ms text field;
user-defined
*.ECMD AUS
Language
Descriptor
3 characters available for describing language
text field;
user-defined
*.ECMD LAO
MPEG 1
Layer 2 Mono or Stereo available if using Encode Mode and MPEG 1 Layer 2
Type\ Mono = [0]
Stereo = [1]
*.ECMD MCM
The Audio Menu repeats for Audio Inputs 1 and 2.
SDI Embedded Audio
SDI embedded audio supports up to 4 Groups, each group has 4 stereo channels:
Group Channels
1 1,2,3,4
2 5,6,7,8
3 9,10,11,12
4 13,14,15,16
The mediaHUB-HDPro can interface with only one group at a time from within the Control Interface. Within the selected group
it hard routes channel 1 to input 1 and channel 2 to input 2. Each of these inputs can encode Dolby AC3, MPEL 1 layer 2, and
can passthrough Dolby 5.1 and Dolby E.
Dolby 5.1
The mediaHub HD Pro cannot encode in Dolby 5.1; it can only encode Dolby 2.0 per audio channel pair.
To encode in Dolby 5.1, an external 5.1 encoder must be plugged into the AES input and that input's mode set to passthrough.
