Adtec digital mediaHUB-HD Pro (version 03.07.19) Manual User Manual
Page 35
SMPTE 259M
SD video
SMPTE 272M
SD embedded audio
SMPTE 292M
HD Video
SMPTE 299M
HD embedded audio
Control and Connectivity
Port
Detail
GigE
MPEG2 or RTP multicast transport egress port
Terminal (COM1)
Back end serial port for Adtec service technicians
API (COM2)
API Serial Communication interface
Fast Ethernet
10/100 base T ethernet interface
Encoder RS422
Sony 9-pin electrical and protocol tape deck interface
GP IO
tally and control port
USB 2.0
not currently supported
Video Sources
SDI (HD-SDI)
SDI Inputs can be in either Standard Definition (SD) or High Definition (HD).
•
SDI inputs are autodetected.
•
SDI Input Rules:
Input Std-definition (SD)- 720x480 (NTSC) or 720x576 (PAL)
can only encode to SD; it is possible to downscale the image to 704H, 640H, 544H, 528H, 480H, or
352H x 480V
◊
does not at present support H scaling in PAL mode
◊
♦
Input Hi-def (HD)- 1280H x 720p..
can only encode to 1280H x720p; no scaling possible
◊
♦
Input Hi-def (HD)- 1920H x 1080i.
can only encode to 1920H x1080i, or downscale and encode to 1440H x1080i
◊
♦
•
Composite
Composite Inputs are in Standard Definition only.
