WES2HT User Manual
Manual-WES2HT-Rev1407-1
Copyright © KBC Networks 2013 Page 22 of 142 www.kbcnetworks.com
4. Point-to-point Kits
There are a number of WES2HT point-to-point kits that are available, details are below:
Part number
Description Contents
WES2HT-KT 5GHz, point-to-point 17dBi kit 1 x 5GHz WES2HT-AA-Cx 17dBi Single-
point Host; 1 x 5 GHz WES2HT-AC-Cx
17dBi Client; 2 x Gigabit LAN power
injectors; 2 x 24VDC Power Supplies; 2 x
pole/wall mounting assemblies.
WES2HT-KT-9 5GHz, point-to-point 9dBi kit 1 x 5GHz WES2HT-AA-Bx 9dBi Single-
point Host; 1 x 5 GHz WES2HT-AC-Bx
9dBi Client; 2 x Gigabit LAN power
injectors; 2 x 24VDC Power Supplies; 2 x
pole/wall mounting assemblies
WES2HT-KT-49 4.9GHz, point-to-point kit Included in the WES2HT-KT-49 is all that
is included in the WES2HT-KT but the
radios are 4.9GHz as opposed to 5GHz.
This system operates on the Public
Safety band and is approved by
FCC/IC to be used by first response
only. It remains the responsibility of the
user to abide by FCC or IC requirements.
WES2HT-KT-P8 5GHz, point-to-point kit with
8 port PoE+ Gig switch &
narrow temperature range
PSU Included in the WES2HT-KT-P8 is all that
is included in the WES2HT-KT as well as:
1 x ESUG8P-D Gigabit Switch + 1 x DRP-
480-48 Power Supply
WES2HT-KT-P8T 5GHz, point-to-point kit with
8 port PoE+ Gig switch &
extended temperature range
PSU Included in the WES2HT-KT-P8T is all that
is included in the WES2HT-KT as well as:
1 x ESUG8P-D Gigabit Switch + 1 x SDR-
480-48 Power Supply
Note:
In the model numbers referenced above “x” is a place holder for the actual
indicator used in the complete model number to identify the global type of power supply
included in the kit.
