WES2HT User Manual
Manual-WES2HT-Rev1407-1
Copyright © KBC Networks 2013 Page 14 of 142 www.kbcnetworks.com
General Technical Specification
WES2HT Specification
Standards
IEEE Standards
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x Full Duplex
IEEE 802.11a 5GHz
IEEE 802.11b 2.4GHz
IEEE 802.11g 2.4GHz
IEEE 802.11y 4.9GHz US Public Safety
IEEE 802.11n MIMO
IEEE 802.11h ETSI DFS & TPC
IEEE 802.3af
Radio
Frequency (MHz)
USA & Canada:
2412 - 2472
4940 - 4990
5745 – 5825
Europe:
2412 - 2472
5500 - 5700
Frequency Operation
Auto-select
User static selectable
Dynamic Frequency Selection (ETSI DFS)
Power Output
23dBm max1
Transmit Power Control (ETSI TPC)
Channel Capacity Selectable 5, 20 or 40MHz
Modulation OFDM
Antennas
2dBi/5dBi (2.4GHz/4.9GHz & 5GHz) Omni-directional
9dBi (4.9GHz & 5GHz)
Directional integrated patch
Dual polarization
Beamwidth:
Azimuth: Horizontal 65°, Vertical 65°
Elevation: Horizontal 33°, Vertical 33°
11dBi (2.4GHz)
Directional integrated patch
Dual polarization
Beamwidth
Azimuth: Horizontal 56°, Vertical 62°
Elevation: Horizontal 38°, Vertical 26°
17dBi (4.9GHz & 5GHz)
Directional integrated patch
Dual polarization
Beamwidth:
1 Territory specific.
2 Assumes an ideal environment with maximum signal rates & within receive
sensitivity specification.
