Azimuth: Horizontal 30°, Vertical 33°
Elevation: Horizontal 17°, Vertical 17°
System
Data throughput2
(max values – limited by 10/100 port) HT5 HT20 HT40
17Mbps 130Mbps 230Mbps
Latency < 10 mS
Power
Power input (supplied by PIM)
24Vdc, 500mA
Reverse voltage protected
Power method (non-PoE WES2HT) Passive PoE
Power method (PoE WES2HT) IEEE 802.3af (PD)
PoE cable spec 100m on 24AWG Cat5/5e/6/6e
Mechanical
Casing IP66
Dimensions (Patch L x W x D)
245mm x 245mm x 76mm
9.625” x 9.625” x 3”
Weight
420g
15oz
Installation Wall-mount or pole-mount
Environmental
Operating Temperature -40° ~ +74°C / -40° ~ +165°F
Storage Temperature -40° ~ +90°C / -40° ~ +194°F
Operating Humidity 5% to 95% non-condensing
Connectors
10/100/1000 Electrical 1 x RJ45
Approvals
FCC Part 15 subpart C Class B
IC ID# 7849A-N523ESD
CE Class B
EN 55024 (IEC61000-4-2,3,4,5,6,8,11) Electromagnetic Immunity
EN 55022 (CISPR 22)
Electromagnetic Interference (Conduction
and Radiation)
EN 60 950: 1992+A1; 1993+A2;
1995+A4; 1996+A1; 1997
Low Voltage Directive
EN 300 328-2
EN 300 826
EN 301 489-17
EN 301 893
R&TT Directive (1999/5/EC)
2 Assumes an ideal environment with maximum signal rates & within receive
sensitivity specification.
