Link connection lines are shown in different colors, these represent different ranges of
RSSI and makes it easy to identify weak RF links.
The WES2HT system mapping tool works with STP enabled as well as STP disabled. The
Root bridge is shown by a green dot and if the Root bridge is lost then this is shown as a
red dot. All wired links are shown as black lines.
Maps can be imported as a background in either JPEG or GIF format. Nodes can then be
moved around on the uploaded map to show them in their physical locations.
If you double click on a node then the embedded UI can be accessed.
The Refresh button can be used to refresh the topology page manually however it is
automatically refreshed every 60 seconds.
The following browsers are supported:
Firefox : 13.0.1 11.0, 10.0.2, 9.0.1
Internet Explorer: 9.0, 8.0
Safari: 5.1.5, 5.1.7
Link Color RSSI Range
Dark green 40dBm and above
Light green 40dBm to 30dBm
Yellow 30dBm to 20dBm
Orange 20dBm to 10dBm
Red 10dBm and lower
Hashed Indicated STP blocked port
