Ethernet Communication Module DVPEN01-SL
DVP-PLC Application Manual 7
CR#
HW LW
Attribute Content Explanation
#7 R
Status of E-Mail 1, 2 b0 ~ b7: Current status of E-Mail 2
b8 ~ b15: Current status of E-Mail 1
#8 R Status of E-Mail 3, 4
b0 ~ b7: Current status of E-Mail 4
b8 ~ b15: Current status of E-Mail 3
#9 R/W
E-Mail 1 additional
message
Filled in by the user, and it will be send by E-mail.
#10 R/W
E-Mail 2 additional
message
Filled in by the user, and it will be send by E-mail.
#11 R/W
E-Mail 3 additional
message
Filled in by the user, and it will be send by E-mail.
#12 R/W
E-Mail 4 additional
message
Filled in by the user, and it will be send by E-mail.
#13 R/W Data exchange trigger Set up whether to send out data in data exchange mode
#14 R Status of data exchange Displaying current status of data exchange.
#24 ~ #15 - Reserved
#26 #25 R/W Destination IP Destination IP address for data exchange
#27 - Reserved
#28 R/W Destination Slave ID Destination Slave ID for data exchange
#48 ~ #29 R/W Data transmission buffer Buffer for transmitted data in data exchange
#68 ~ #49 R Data receiving buffer Buffer for received data in data exchange
#69 R/W DHCP/Static IP Selecting DHCP or Static IP
#71 #70 R/W IP address Setting up IP address
#73 #72 R/W Subnet mask Setting up subnet mask of DVPEN01-SL
#75 #74 R/W Gateway Setting up default gateway IP address
#76 R IP status Displaying current IP status
#80 ~ #77 - Reserved
#81 R/W
Read address for data
exchange
Slave transmission buffer address for data exchange
#82 R/W
Read length for data
exchange
Number of registers for read data
#83 R/W
Received address for
data exchange
Buffer address for the receiving Master in data exchange
#84 R/W
Written-in address for
data exchange
Buffer address for the receiving Slave in data exchange
#85 R/W
Written-in length for data
exchange
Number of registers for data transmission
#86 R/W
Transmission address
for data exchange
Master transmission buffer address for data exchange
#110 ~ #87 - Reserved
#111 R/W 8-bit processing mode Setting up Modbus TCP Master control as 8-bit mode
#113 ~ #112 - Reserved
#114 R/W Modbus TCP time-out Setting up Modbus TCP time-out (in ms)
#115 R/W Modbus TCP trigger Setting up whether to send out data in Modbus TCP mode
#116 R/W Modbus TCP status Displaying current status of Modbus TCP mode
#118 #117 R/W
Modbus TCP
destination IP
Setting up destination IP address for Modbus TCP transaction
