SCS-1R Installation Guide Digital Monitoring Products
25
OPERATOR’S GUIDE
each substituted panel. Subsequent messages from substituted panels do not generate
additional S58 messages. Default is YES.
When NO is selected, substituted panels are not sent acknowledgments for their
messages. For each message received from a substituted panel, an S58 Alarm: Panel
Substitution message is sent to the host automation computer and receiver printer.
Note: Set this option to YES for all receiver installations except for Canadian receiver
installations where the security requirement is ULC Active Level 3.
CHECKIN TABLE IP
000.000.000.000
Check-in Table IP Address
The optional SCS-CTM Check-in Table Manager software is used to backup the records
of supervised network accounts on up to 32 different SCS-104 line cards. Use SCS-CTM
to repopulate the list of supervised network accounts when one SCS-104 or SCS-101
line card is replaced by another SCS-104 or SCS-101. Additionally, the list of supervised
network accounts used by an SCS-104 or SCS-101 on a primary receiver can be mirrored
by the SCS-CTM for use by an SCS-104 or SCS-1011 card on a second receiver. Refer to
the SCS-CTM User’s Guide (LT-0940).
Note: The list of supervised network accounts on an SCS-104 line card is automatically
populated as each panel sends its supervisory check-in message to the SCS-104 line card.
Enter the IP address for the computer where the SCS-CTM Check-in Table Manager
software is installed. When no SCS-CTM software is installed, leave the IP address set
to 000.000.000.000.
CHECKIN TABLE
PORT: 2005
Check-in Table Port
Enter the IP port used to communicate Check-In Table messages to the SCS-CTM
Check-in Table Manager program. Valid range is 1 to 65,535. Default is 2005.
CHECKIN TABLE
ID: 1
Check-in Table ID
Enter the table ID number to be used by the SCS-CTM Check-in Table Manager to
identify the check-in table. Valid range is 1 to 255. Default is 1.
Exiting Network Line Setup
When done, press the COMMAND key once to return to the Card Number prompt. The next Card Number in
sequence will be displayed.
Host Automation
The SCS-1R Host Automation programming section allows adjustments to optimize the SCS-1R performance with
the host automation computer. The display shows the current setting for each prompt. Press any top row Select
key to clear the display and enter the new information.
SCS-1R MENU
HOST AUTOMATION
Host Automation
Press any top row Select key to program Host Automation settings. Press the COMMAND
key to advance to the next programming section. Press the Back Arrow key to return to
the previous section.
HOST NAME
HOST 1 NAME
Host Name
Enter a Host Name up to 16 characters. When done, press Command to accept name
and continue to HOST PORT TYPE. Default is HOST 1 NAME.
HOST PORT TYPE:
SERIAL
Host Port Type
Select SERIAL to send messages to the host automation computer through the Host
Output serial port on the SCS-203 Convenience panel located on the back of the
receiver. Select NETWORK to send messages through the network connection on the
SCS-150 to the host automation computer. Default is SERIAL.
HOST IP ADDRESS:
192.168.000.250
Host IP Address
Enter the Host IP Address. This is the IP address of the host automation computer. The
default value is 192.168.000.250.
HOST PORT:
2001
Host Port
The Host Port identifies the port on the host automation computer. Valid range is 1 to
65,535. The default value is 2001.
Protocol
Select TCP to communicate with the host automation computer over the network using
TCP protocol. Select UDP to communicate using UDP protocol. Default is TCP.
START CHARACTER :
NONE
Start Character
Enter the character to be used at the start of a host message. Enter None or 01-12 or
14-31. Default is NONE.
HOST PORT TYPE:
SERIAL NETWORK
UDP TCP
PROTOCOL: TCP
