Modular Block System: Emergency Stop Circuits 6-37
Table for setting the global parameters:
INFORMATION
• All times must be entered in ms.
• The values suggested are default values. If working with these values
produces nuisance errors, you can determine which values would be
suitable as follows:
- Start from the default value
- Increase this value in stages until the nuisance errors stop.
Input Parameters in Limits Suggested
parameters Admin.-DB in [ms] values in [ms]
CoSy DW 1001 0... 255 50
RFbL DW 1002 0... 255 100
CS_B DW 1003 0... 255 100
CS_R DW 1004 0... 255 50
MaCy DW 1005 0... 30 000 30 000, conforming
to EN 61 496-1
A.8.4/C.6.2
ESPE DW 1006 0... 255 150, conforming
to EN 61 496-1
Reserved DW 1007
DW 1008
DW 1009
Reserved DW 1010
DW 1011
DW 1012
DW 1013
DW 1014
Reserved DW 1015
DW 1016
DW 1017
DW 1018
Reserved DW 1019 Administration
Reserved DW 1020
Reserved DW 1021
Reserved DW 1022 Min. scan time DB002/DW0002
Reserved DW 1023
