2-1 Modular Block System: Emergency Stop Circuits
Software package
The “MBS Emergency Stop Circuits” software package is part of the Pilz
MBS Modular Block System. The software package contains all the
standard function blocks necessary for electronically-monitored safety
devices on distributed automation plants. This includes:
• Evaluation of E-STOP buttons, grab wires etc.
• Monitoring safety, maintenance and supply gates
Standard function blocks in the “MBS Emergency Stop Circuits” software
package are used in the failsafe section of a PSS-range programmable
safety system.
Range
The software package consists of:
• The files for the software package on CD and
• An operating manual:
PSS Standard Function Blocks MBS Emergency Stop Circuits, Version
2.0
The software package on the CD contains the following standard function
blocks:
• SB060 NA_Kat_2
Monitoring E-STOP button up to category 2 in accordance with
EN 954-1, 03/97 and AK 3 in accordance with DIN V 19 250,
01/89
(approved safety block)
• SB061 NA_1
Monitoring E-STOP button up to category 4 in accordance with
EN 954-1, 03/97 and AK 6 in accordance with DIN V 19 250,
05/94
(approved safety block)
• SB062 E-STOP
Monitoring E-STOP button up to category 4 in accordance with
EN 954-1, 03/97 and AK 6 in accordance with DIN V 19 250,
05/94
(approved safety block)
