6-6 Modular Block System: Emergency Stop Circuits
Standard Function Blocks
SB060: Emergency stop monitoring, category 2
Block header
Input parameters
• SSNR: Safety subroutine number
Permitted value range: 1 ... 200
Format: Byte constants KB001 ... KB200
(see sections in Chapter 5 entitled “Administration data blocks
DB015, DB016 and DB017” and “Input parameter SSNR”).
• EIN: Reset button (N/O contact)
EIN = 0/1-pulse edge: Reset occurs
• S1_Ö : E-STOP N/C contact
• QAnf: Automatic reset (PSS cold start)
QAnf = RLO-0 (M 110.00): No reset required.
Cycle: When the PSS is started up (PSS switched
off/on) or cold started (PSS STOP/RUN), the
enable is triggered without an additional reset.
QAnf = RLO-1 (M 110.01): Reset required.
Cycle: When the PSS is started up (PSS switched
off/on) or cold started (PSS STOP/RUN), a reset
is required through the input parameter
EIN in
order to trigger the enable.
• QAut: Automatic reset when E-STOP button is released
QAut = RLO-0 (M 110.00): Reset through input parameter EIN
is required.
QAut = RLO-1 (M 110.01): Automatic reset when E-STOP is
released. The value of input parameter EIN is
irrelevant.
SB060
SB 060
NA_Kat_2
B - SSNR
X - EIN
X - S1_Ö
X - QAnf
X - QAut FG - X
