8-1
8.1 Technical details
8 Technical details
8 8000 Technical details Technical details 8- 8.1 Technical details 8100 Technical details 8- ][Technische Daten PSSu seriell(-T)
Technical details
Application range Standard
Module's device code 0721h
Number of ST input bits 64
Number of ST output bits 64
Number of ST status bits 16
Number of ST control bits 16
Support in system environment A yes
from ST firmware version for other head modules 17
from ST firmware version PSSu H S PN 1
Support in system environment B yes
from head module ST firmware version 1.0.0
Electrical data
Internal supply voltage (module supply)
Supply voltage range of module supply
4.8 - 5.4 V
Module's current consumption 95 mA
Module's power consumption 0.48 W
Periphery's supply voltage (periphery supply)
Voltage range
16.8 - 30.0 V
Module's current consumption 11 mA
Module's power consumption 0.26 W
Max. power dissipation of the module 0.80 W
Serial interface
Number of RS485 interfaces
1
Transmission rate (configurable) 1.2 kBit/s, 19.2 kBit/s, 2.4 kBit/s, 300 Bit/s, 4.8 kBit/s,
600 Bit/s, 9.6 kBit/s
Max. cable run 1,000 m
Size of receive buffer 1,023 Byte
Size of send buffer 127 Byte
Potential isolation between interface and Module Supply yes
Potential isolation between interface and Periphery Supply yes
Environmental data
Climatic suitability
EN 60068-2-14, EN 60068-2-1, EN 60068-2-2, EN 60068-
2-30, EN 60068-2-78
Ambient temperature in accordance withEN 60068-2-14 -40 - 70 °C T-type
0 - 60 °C
Storage temperature in accordance with EN 60068-2-1/-2 -25 - 70 °C
-40 - 70 °C T-type
Climatic suitability in accordance with EN 60068-2-30, EN
60068-2-78 93 % r. h. at 40 °C
Condensation yes T-type
no
Max. operating height above sea level 2000 m
5000 m T-type
EMC EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-
4-5, EN 61000-4-6, EN 61131-2
Vibration to EN 60068-2-6
Frequency
10 - 1,000 Hz T-type
10 - 150 Hz
Max. acceleration 1g
5g T-type
