6-3
6.1 General wiring guidelines
6 Wiring
46228, 0.14 ... 1.5 mm
2
, Form A or C, although this is not essential.
To crimp the ferrules you can use crimp pliers (crimp form A or C)
conforming to EN 60947-1, such as the PZ 1.5 or PZ 6.5 from Wei-
dmüller, for example.
– Maximum torque setting: 0.8 Nm
 Use copper wiring.
