Technical Details
Operating Manual PSSu E S PD-D
21975-EN-04
26
Environmental data 312197
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10,0 - 150,0 Hz
Max. acceleration 1g
Shock stress
In accordance with the standard EN 60068-2-27
Acceleration 15g
Duration 11 ms
In accordance with the standard EN 60068-2-29
Acceleration 10g
Duration 16 ms
Max. operating height above sea level 2000 m
Airgap creepage
In accordance with the standard EN 60664-1, EN 61131-2
Overvoltage category II
Pollution degree 2
Protection type
In accordance with the standard EN 60529
Mounting (e.g. cabinet) IP54
Housing IP20
Mechanical data 312197
Material
Bottom PC
Front PC
Coding PA
Dimensions
Height 76,0 mm
Width 12,6 mm
Depth 60,2 mm
Weight 34 g
Mechanical coding
Type J
Colour Dark grey
The standards current on 2008-04 apply.
