6.2

Preparing for operation

6

Commissioning

Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

6-6

6.2.3

Connection of proximity switches and incremental encoder

Connection of proximity switches and incremental encoder

6-

6.2.3.1

Proximity switch and incremental encoder on various axes

Proximity switch and incremental encoder on various axes

6-

Drehzahlwaechter_Betriebs_Naeherungssch_u_Inkremen_versch_Achs_BA

Axis 1:

proximity switch on I10, I11

or

incremental encoder on X12

Axle 2:

proximity switch on I10, I21

or

incremental encoder on X22

Fig. 6-6:

Proximity switch and incremental encoder on various axes

I20

I11

I21

I10

0 V

L+
L-

X12

X22

Axis 2
