Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]

8-1

8.1

Technical details

8

Technical Details

8

8000

Technical Details

Technical Details

8-

8.1

Technical details

8100

Technical details

8-

][Technische Daten_multi_Analogeingangsmodul

Technical details

Electrical data
Supply voltage
Supply voltage U

B

DC

24 V

Voltage tolerance

-15 %/+20 %

Power consumption at U

B

DC

2.0 W

Residual ripple DC

5 %

Times
Switch-on delay

5.00 s

Max. reaction time when the input signal changes

100 ms

Supply interruption before de-energisation

20 ms

Inputs
Number of analogue inputs

2

Type of analogue inputs

Voltage, Current

Max. measurement error at 25 °C

0.5 %

Temperature coefficient*

0.0025 %/K

Max. measurement error at full temperature range

0.5 %

Greatest transient deviation during el. interference test

1.0 %

Max. measurement error in the case of a potential module
error

1.5 %

Max. voltage between the I0 and I1 inputs during current or
voltage measurement

30 V

Analogue input filter

first order, RC filter

Cutoff frequency

80 Hz

Filter time constant

2.0 ms

Galvanic isolation

no

Current measurement
Signal range

0.00 - 25.59 mA

Value range

0 - 4095 d

Resolution

12 Bit

Value of least significant bit (LSB)

6.25 µA

Input resistance (current input)

100.000 Ohm

Max. continuous current

50 mA

Voltage measurement
Signal range

-10.2400 - 10.2375 V

Value range

-4096 - 4095 d

Resolution

13 Bit

Value of least significant bit (LSB)

5 mV

Input resistance (voltage input)

290 kOhm

Max. continuous voltage

+/- 30 V

Environmental data
EMC

EN 60947-5-1

Vibration to EN 60068-2-6
Frequency

10 - 55 Hz

Amplitude

0.35 mm

Climatic suitability

EN 60068-2-1,
EN 60068-2-30, EN 60068-2-78 coated version

Airgap creepage in accordance with

EN 60664-1

Ambient temperature

0 - 60 °C
-25 - 60 °C
coated version

Climatic suitability

95 % r. F. coated version
