efore beginning this installation, please read through this entire instruction booklet and the

Street Supercharger System Owner's Manual which includes the Automotive Limited Warranties

Program and the Warranty Registration form.
Vortech supercharger systems are performance improving devices. In most cases, increases in

torque of 30-35% and horsepower of 35-45% can be expected with the boost levels specified by

Vortech Engineering. This product is intended for use on healthy, well maintained engines.

Installation on a worn-out or damaged engine is not recommended and may result in failure of the

engine as well as the supercharger.

Vortech is not responsible for engine damage.

Installation on new vehicles will not harm or adversely affect the break-in period so long as factory

break-in procedures are followed.
For best performance and continued durability, please take note of the following key points:

1. Use only premium grade fuel 91 octane or higher (R+M/2).

2. The engine must have stock compression ratio.

3. If the engine has been modified in any way, check with Vortech prior to using this product.

4. Always listen for any sign of detonation (pinging) and discontinue hard use (no boost) until

problem is resolved.

5. Perform an oil and filter change upon completion of this installation and prior to test driving

your vehicle. Thereafter, always use a high grade SF rated engine oil or a high quality syn-

thetic, and change the oil and filter every 3,000 miles or less. Never attempt to extend the

oil change interval beyond 3,000 miles, regardless of oil manufacturer's claims as potential

damage to the supercharger may result.

6. Before beginning installation, replace all spark plugs that are older than 1 year or 10,000

miles with original heat range plugs as specified by the manufacturer and reset timing to

factory specifications (follow the procedures indicated within the factory repair manual and/

or as indicated on the factory underhood emissions tag). Do not use platinum spark plugs

unless they are original equipment. Change spark plugs at least every 15,000 miles and

spark plug wires at least every 50,000 miles.

TOOL & SUPPLY REQUIREMENTS

• Factory Repair Manual

• 3/8" Socket and Drive Set: SAE & Metric

• 1/2" Socket and Drive Set: SAE & Metric

• 3/8" NPT Tap and Handle

• Adjustable Wrench

• Open End Wrenches: 3/8", 7/16", 1/2",

9/16"

• Center Punch and a 5/8" Tapered Punch

• Springlock 3/8" and 5/8”Fuel Fitting

Disconnect Tool

• 5 Quarts SH/CF Rated Quality Engine

Oil

• Oil Filter and Wrench

• Flat #2 Screwdriver

• Phillips #2 Screwdriver

• Heavy Grease

• Silicone Sealer

• Drill Motor

• 1/8", 3/16", 27/64" Drill Bits

• 3/8" Tube Bender

GM 2001-2002, 2004, 2006 Denali/2002-2004

Cadillac Escalade/

2003-2008 H2 Hummer/2003-2004 SS Truck

50 State Legal Per CARB EO D-213-25* (2007-2008 Models NOT 50-State Legal.)

Congratulations on selecting the best performing and best backed automotive

supercharger available today... the VORTECH® V-2® Supercharger!

• 3/16" Allen Wrench

• Wire Strippers and Crimpers

• Utility Knife

• Power Steering Pulley/Puller & Installer

• Pliers

• Power steering pulley installer/puller

If your vehicle has in excess of 10,000

miles since its last spark plug change,

then you will also need:

• Spark Plug Socket

• NEW Spark Plugs

GIN

EER

ING

, LL
