P/N: 4GL020-015
©2008 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
08OCT08 GM Trk/H2(4GL..015v5.0)
8F060-005 8.1L INJECTORS 8
4809639 INSTR. MANUAL DENALI/ESCALADE/HUMMER 1
4GL011-021
MTG BRKT GM TRUCK MACH. 1
2E228-390 V2SQ S-TRIM LS1 TRK 1
2A036-333 S/C PULLEY 3.33" 6-GRV 1
4GL112-040 AIR INLET ASY, H2 HUMMER 1
4GL012-015 DUCT, INLET, HUMMER H2 TRK 1
7P156-082 5/32" TEE 1
7R002-016 #16 SAE TYPE “F” SS HOSE CLAMP 4
7R002-052 #52 SAE TYPE “F” SS HOSE CLAMP 2
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 4
7S350-300 3-1/2" x 3" SLEEVE 1
7U030-046 Ø5/32" VACUUM LINE 1
7U030-056 Ø3/8" PVC/VAC RUBBER HOSE 2
7U034-016 Ø1" GS HOSE 0.33'
7U035-001 Ø3-1/2" FLEX HOSE 0.83'
7U375-052 3/8" VACUUM CAP 1
8D001-001 STD COMPRESS BYPASS VALVE 1
4PGL010-011 BRKT, D-SIDE H2 TRK AIR INLET 1
4PGL010-012 BRKT, P-SIDE H2 TRK AIR INLET 1
7A250-050 1/4-20 x .50" SHCS ZINC PLTD 2
7J006-093 6mm WASHER, PLTD 2
7P375-050 3/8" HOSE UNION, BRASS 1
4PGL012-061 INLET DUCT, MACH H.O. LS1 TRK 1
7S350-200 3-1/2" x 2" SLEEVE 1
7U133-045 RUBBER ELBOW, Ø1" x 45° 1
7C060-050 M6-1.0 x 50mm HXHD ZINC PLTD 2
7J250-150 1/4" FENDER WASHER ZN PLTD 2
7F006-093 6mm NYLOCK NUT 2
2A017-752-02 SPACER, .750"OD x .894"LONG 2
7P625-375 REDUCER, 5/8" BARB x 3/8" BARB 1
7U033-000 5/8" PVC HOSE 0.16'
7S300-275 REDUCER, Ø3.00" x Ø2.75" 1
4GL130-036 OIL DRAIN ASY 1
7P375-017 3/8"NPT x 1/2" BEADED HOSE BARB 1
7P375-040 3/8" FEMALE ELBOW 1
7P375-041 3/8"NPT HEX NIPPLE 1
7R001-008 #8 STAINLESS HOSE CLAMP 2
7R003-016 ADEL CLAMP, 1.0" 1
7U030-036 Ø1/2" OIL DRAIN HOSE 2.75'
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
4PGL130-026 OIL FEED ASY 1
7U100-055 TIE-WRAP, 6" NYLON 2
7C060-050 M6 x 1.0" x 50 HXHD ZINC PLATE 2
7J006-093 6mm WASHER PLTD 2
4GL010-020 ADAPTER, ESCALADE OIL FEED 1
4GL010-030 GASKET, ESCALADE OIL ADAPTER 1
4GL010-040 GASKET, 5.3 OIL ADAPTER 1
7U250-400 OIL FEED HOSE, 40" -4 x 90° 1
7P125-005 1/8"NPT STR x -4 JIC FTG 1
7P125-004 1/8"NPT x 90° JIC FTG 2
4PGL101-001 FUEL PUMP ASY 1
7P250-047 1/4"NPT to 3/8" BARB x 90° 1
7P312-002 5/16" BARB x 1/4"NPT FEM 1
7R004-002 STEPLESS CLAMP, 17.0-70 4
7R004-001 STEPLESS CLAMP, 15.7-70 2
7U031-018 Ø5/16" EFI FUEL HSE HI-PSR 1.25'
7U032-016 Ø3/8" EFI FUEL HSE HI-PSR .167'
7U032-016 Ø3/8" EFI FUEL HSE HI-PSR .5'
7U100-044 TIE-WRAP, 4" NYLON 10
7U100-055 TIE-WRAP, 6" NYLON 10
8F001-500 PUMP, FUEL, “PRO-FLO 500” 1
7U033-010R HOSE, 5/8"ID p/STEERING RET 2
2003 H2 Hummer
Part No. 4GL218-070/078SQ
5W001-042 12-10GA x 3/16" RING TERMINAL 3
7P375-072 3/8" FEMALE FUEL FTG, STEEL 1
7P625-375 REDUCER, 5/8" BARB x 3/8" BARB 1
7P375-010 3/8" GM FUEL x 3/8" BARB FTG 1
7F012-001 M12 CAP HEX NUT, FUEL PUMP 1
7R003-028 ADEL CLAMP, 2-3/8" x .26" HOLE 2
7P312-015 FTNG, BANJO 12mm x .312" BARB 1
7R004-004 STEPLESS CLAMP, 1.0"OD HOSE 2
7E010-075 #12 x 3/4" SHT METAL SCRW, HEX 3
5W012-000 12GA STRD WIRE, RED 15'
5W001-040 12-10GA FEMALE SLIDE INSULATED 1
5W012-010 12GA WIRE, BLACK .5'
7R003-008 ADEL CLAMP, 1/2"ID 2
8F101-320 RELAY ASY, LS1 TRK 1
8N107-050 WATER PUMP ASY. 1
8F001-402 WATER PUMP 1
7R003-027 ADEL CLAMP 1-11/16" 1
5W001-025 FEMALE SLIDE MINI 1
5W001-043 12-10GA x 1/4" RING TERMINAL 3
7A250-050 1/4-20 x .50" SHCS 2
5W001-013 14-16GA BUTT-CONNECTORS 4
5W001-019 12-10GA BUTT-CONNECTORS 2
7U100-044 4" TIE-WRAPS 4
5W001-022 T-SPLICE CONNECTOR 1
7F250-021 1/4-20 NYLOCK NUT 1
5W001-015 FUSE, BLADE TYPE 20AMP 1
5W001-005 3/8" PLASTIC WIRE LOOM 2
5W001-014 FUSE HOLDER 10GA WIRE 1
7U100-055 TIE-WRAP, 6" NYLON 6
5W001-041 12-10GA MALE SLIDE INSULATED 2
8F101-320 WATER PUMP RELAY ASY, LS1 TRK 1
8N105-050 WATER TANK ASY 1
8N055-030 LT1 WATER TANK 1
7P500-026 90° BARBED BRASS FITTING 2
4PGL010-060 BRKT “A” 1
4PGL010-070 BRKT “B” 1
4PGL010-080 BRKT “C” 1
7A250-102 1/4-20 x 1" SHCS 1
7J250-022 1/4" WASHER 6
7F250-021 1/4-20 NYLOCK NUT 1
8N056-060 SURGE TANK 1
8N055-050 SURGE TANK CAP 1
4PGL010-090 BRKT, SURGE TANK 1
7P500-078 12"NPT x 3/4" HOSE FIT 2
7U038-020 MOLDED “S” HOSE 1
7A250-050 1/4-20 x .5" SHCS 4
7U038-000 Ø3/4" HEATER HOSE 10
7U033-000 Ø5/8" HOSE 5
7P750-625 3/4-5/8" REDUCER BARB 2
7E010-075 #12 x 3/4" SHT METAL SCRW HEX 4
7U030-065 90° MOLDED ELBOW SHORT 1
7J010-001 #10 FLAT WASHER 2
7R002-020 #20 HOSE CLAMP 2
7R007-002 NYLON CLAMPS 7/8" 4
7R007-001 NYLON CLAMPS 1-1/8" 10
8N201-078 POWER COOLER ASY 1
8N101-118 WELDED CORE ASY V-10 S.D. 1
7P500-078 1/2"NPT x 3.4" HOSE FIT 1
7P500-026 1/2"NPT x 3/4" HOSE BARB 90° 1
2A017-875-13 SPACER, CAC BRKT 1
7C010-040 10mm-1.5 x 1.5mm SCREW 1
7J010-002 10mm WASHER 1
7U250-200 COOLER FOAM 1
4GL010-050 COOLER REST BRACKET 1
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or
damaged parts immediately.
PARTS LIST
®
