Vortech 2003-2004 Chevrolet SS User Manual

Page 26

P/N: 4GL020-015

08OCT08 GM Trk/H2(4GL..015v5.0)

OIL FEED LINE (ENGINE OIL-FED KITS ONLY. APPLICATIONS WITH V-3

SUPERCHARGER SKIP AHEAD TO STEP 8)

A. Remove the two screws holding the small

casting or oil cooler block located directly

above the oil filter.

B. Using engine oil on the threads, install

1/8"NPT to #4 90° fitting into the supplied oil

feed adapter.

C. Locate the supplied gasket that matches the

factory gasket that was removed. Using the

adapter, the appropriate supplied gasket and

the supplied longer 6mm screws, assemble

the components as shown in Fig. 6-a).

D. Install a 1/8"NPT to #4 90° fitting into the

supercharger oil feed filter. Use a small

amount of engine oil on the pipe threads.

Install the 90° end of the stainless steel oil

feed line to the 90° fitting already installed on

the supercharger. Orient the hose so that it is

pointing to the rear of the vehicle. This will

allow the air inlet tube to have clearance that

is installed later.

E. Route the oil feed line from the supercharger

to the installed fitting. Use an adel clamp on

the side of the oil pan and tie wraps to secure

the oil feed and oil drain lines and protect

them from kinking, abrasion and high heat

areas. (See Fig. 6-a.)

F. Drain the engine oil, install a new filter and

refill the engine with fresh oil.

NOTE: Pipe sealant should not be used as it can clog the fil-

ter and damage the supercharger.
