Vortech 2003-2004 Chevrolet SS - Manual (Page 12)

xii
P/N: 4GL020-015
©2008 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
08OCT08 GM Trk/H2(4GL..015v5.0)
8F060-005 8.1L INJECTORS 8
4809639 INSTR. MANUAL DENALI/ESCALADE/HUMMER 1
4GL011-021
MTG BRKT GM TRUCK MACH. 1
2E228-390 V2SQ S-TRIM LS1 TRK 1
2A036-333 S/C PULLEY 3.33" 6-GRV 1
4GL112-040 AIR INLET ASY, H2 HUMMER 1
4GL012-015 DUCT, INLET, HUMMER H2 TRK 1
7P156-082 5/32" TEE 1
7R002-016 #16 SAE TYPE “F” SS HOSE CLAMP 4
7R002-052 #52 SAE TYPE “F” SS HOSE CLAMP 2
7R002-056 #56 SAE TYPE “F” SS HOSE CLAMP 4
7S350-300 3-1/2" x 3" SLEEVE 1
7U030-046 5/32" VACUUM LINE 1
7U030-056 3/8" PVC/VAC RUBBER HOSE 2
7U034-016 Ø1"GS HOSE 0.33'
7U035-001 Ø3-1/2" FLEX-HOSE 0.83'
7U375-052 3/8" VACUUM CAP 1
8D001-001 STD COMPRESS BYPASS VALVE 1
4PGL010-011 BRKT, D-SIDE H2 TRK AIR INLET 1
4PGL010-012 BRKT, P-SIDE H2 TRK AIR INLET 1
7A250-050 1/4-20 x .50" SHCS ZINC PLTD 2
7J006-093 6mm WASHER, PLTD 2
7P375-050 3/8" HOSE UNION, BRASS 1
4PGL012-061 INLET DUCT, MACH H.O. LS1 TRK 1
7S350-200 3-1/2" x 2" SLEEVE 1
7U133-045 RUBBER ELBOW, Ø1" x 45° 1
7C060-050 M6-1.0 x 50mm HXHD ZINC PLTD 2
7J250-150 1/4" FENDER WASHER ZN PLTD 2
7F006-093 6mm NYLOCK NUT 2
2A017-752-02 SPACER, .750"OD x .894"LONG 2
7P625-375 REDUCER, Ø5/8" BARB TO Ø3/8" BARB 1
7U033-000 Ø5/8" PVC HOSE 0.16'
7S300-275 REDUCER, Ø3.00" x Ø2.75" 1
7U033-000 Ø5/8" PCV HOSE .16'
7P375-113 PCV VALVE, VIPER, 3/8" x 1/2" BA 1
7U375-056 Ø3/8" PCV/VAC RUBBER HOSE .25'
4GL130-036 OIL DRAIN ASY 1
7P375-017 3/8"NPT x 1/2" BEADED HSE BRB 1
7P375-040 Ø3/8" FEMALE ELBOW 1
7P375-041 3/8"NPT HEX NIPPLE 1
7R001-008 #8 STAINLESS HOSE CLAMP 2
7R003-016 ADEL CLAMP, 1.0" 1
7U030-036 Ø1/2" OIL DRAIN HOSE 2.75'
7T560-001 CUTTER, 9/16" ROTABROACH 1
7T560-002 ARBOR, ROTABROACH 1
4PGL130-026 OIL FEED ASY 1
7U100-055 TIE-WRAP, 6" NYLON 2
7C060-050 M6-1.0 x 50mm HXHD ZINC PLATE 2
7J006-093 6mm WASHER PLTD 2
4GL010-020 ADAPTER, ESCALADE OIL FEED 1
4GL010-030 GASKET, ESCALADE OIL ADAPTER 1
4GL010-040 GASKET, 5.3 OIL ADAPTER 1
7U250-400 OIL FEED HOSE, 40" x -4 x 90° 1
7P125-005 1/8"NPT STR x -4 JIC FTG 1
7P125-004 1/8"NPT x 90° x JIC FTG 2
8N107-050 WATER PUMP ASY 1
8F001-402 WATER PUMP 1
7R003-027 ADEL CLAMP 1-11/16" 1
5W001-025 FEMALE SLIDE MINI 1
5W001-043 12-10GA x 1/4" RING TERMINAL 3
7A250-050 1/4-20 x .50" SHCS 2
5W001-013 14-16GA BUTT CONNECTORS 4
2004-2007 H2 Hummer
Part No. 4GL218-090/098SQ (2004 Models)
Part No. 4GL218-150/158SQ (2005-2007 Models)
5W001-019 12-10GA BUTT CONNECTORS 2
7U100-044 4" TIE-WRAPS 4
5W001-022 T-SPLICE CONNECTOR 1
7F250-021 1/4-20 NYLOCK NUT 1
5W001-015 FUSE, BLADE TYPE 20AMP 1
5W001-005 3/8" PLASTIC WIRE LOOM 2
5W001-014 FUSE HOLDER 10GA WIRE 1
7U100-055 TIE-WRAP, 6" NYLON 6
5W001-041 12-10GA MALE SLIDE INSULATED 2
8F101-320 WATER PUMP RELAY ASY, LS1 TRK 1
8N105-050 WATER TANK ASY 1
8N055-030 LT1 WATER TANK 1
7P500-026 90° BARBED BRASS FITTING 2
4PGL010-060 BRKT “A” 1
4PGL010-070 BRKT “B” 1
4PGL010-080 BRKT “C” 1
7A250-102 1/4-20 x 1" SHCS 1
7J250-022 1/4" WASHER 6
7F250-021 1/4-20 NYLOCK NUT 1
8N056-060 SURGE TANK 1
8N055-050 SURGE TANK CAP 1
4PGL010-090 BRKT, SURGE TANK 1
7P500-078 12"NPT x 3/4" HOSE FIT 2
7U038-020 MOLDED “S” HOSE 1
7A250-050 1/4-20 x .5" SHCS 4
7U038-000 Ø3/4" HEATER HOSE 10"
7U033-000 Ø5/8" HOSE 5"
7P750-625 Ø3/4" x Ø5/8" REDUCER BARB 2
7E010-075 #12 x 3/4" SHT METAL SCRW HEX 4
7U030-065 90° MOLDED ELBOW SHORT 1
7J010-001 #10 FLAT WASHER 2
7R002-020 #20 HOSE CLAMP 2
7R007-002 NYLON CLAMPS 7/8" 4
7R007-001 NYLON CLAMPS 1-1/8" 10
8N201-078 POWER COOLER ASY 1
8N101-118 WELDED CORE ASSEMBLY V-10 S.D. 1
7P500-078 1/2"NPT x 3.4" HOSE FIT 1
7P500-026 1/2"NPT x 3/4" HOSE BARB x 90° 1
2A017-875-13 SPACER, CAC BRKT 1
7C010-040 10mm-1.5" x 1.5mm SCREW 1
7J010-002 10mm WASHER 1
7U250-200 COOLER FOAM 1
4GL010-050 COOLER REST BRACKET 1
4PGL112-028 DISCH ASY 1
4GL012-041 6.0 TUBE “A” 1
4GL012-051 6.0 TUBE “B” 1
4GL012-030 ELBOW, 3.88" - 3.0" x 90° LS1 TRK 1
7R002-044 #44 GOLDSEAL HOSE CLAMP 5
7R002-048 #48 GOLDSEAL HOSE CLAMP 2
7R002-064 #64 GOLDSEAL HOSE CLAMP 1
7S275-200 2-3/4" x 2" SLEEVE 2
7S300-275 3.00" x 2.75" REDUCER SLEEVE 1
8N106-075 WATER COOLER ASY 1
8N006-005 WATER COOLR, SETRAB DUAL-PASS 1
7A250-102 1/4-20 x 1" SHCS SS 4
7J250-022 1/4" WASHER SAE STAINLESS 8
7F250-021 1/4-20 NYLOCK NUT, ZINC PLT 2
8N010-140 MTG TAB, SETRAB 2-PASS COOLR 4
7P375-075 3/4" HOSE BARB UNION, BRASS 3
7U125-200 TAPE, FOAM, 1/8" x 2" x 50' 7.5"
7U038-020 HOSE, Ø3/4" “S” MOLDED RUBBER 2
7R007-001 NYLON RATCHET CLAMP, 1-1/8" 4
4GL020-020 MTUNER CREDIT TAG (2004 MODEL YEAR) 1
5A003-034 DIABL0 PREDATOR (2003-2007 MODEL YEAR) 1
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or
damaged parts immediately.
*
It is recommended that you use the K061140 drive belt.
PARTS LIST
®
ENGINEERING, LLC
