RS232 Params Menu
The RS232 Params menu configures the external serial ports of the RAID Controller. The RAID
Controller can communicate with a remote terminal (refer to section "Monitor Utility" for further
information).
NOTE: The RAID Controller and remote terminal must be configured to the same communication
settings (baud rate, stop bit, data bit, and parity).
Sub-Menu Settings/Options Default
31 Modem Port
311 Baud Rate 2400 , 4800 , 9600 , 14400 , 19200
19200 , 28800 , 57600 , 115200
312 Stop Bit 1, 2 1
313 Data Bit 7, 8 8
314 Parity None, Odd, Even None
Use to specify the communication protocol between the controller and external modem. Refer
to Table 7 for modem port settings.
Table 7: Modem & Terminal Port Settings
32 Terminal Port
321 Baud Rate 2400 , 4800 , 9600 , 14400 , 19200
19200 , 28800 , 57600 , 115200
322 Stop Bit 1, 2 1
323 Data Bit 7, 8 8
324 Parity None, Odd, Even None
Use to specify the communication protocol between the controller and remote terminal. Refer
to Table 7 for terminal port settings.
Parameter Value
Baud Rate
Data Bits
Stop Bits
Parity
2400, 4800, 9600, 14400, 19200,
28800, 38400, 57600, 115200
7, 8
1, 2
None, Odd, Even
Default Value
19200
8
1
None
