16 Installation
StorCase Technology, Inc. DS560/DS570 User's Guide - Rev. A04
Figure 10: Typical Dual Channel RAID Configuration
to SCSI
Host 1
to SCSI
Host 2
VT-100/ANSI
Terminal
External
Modem
S_IDE10
Typical Dual Channel RAID Configuration
NOTES: The installation, configuration, and use of the SCSI-IDE RAID Controller
requires a certain level of expertise and experience on the part of the user/
integrator. Since there are many configuration options and variables (ie.
host platforms, applications, etc.), only general guidelines will be dis-
cussed in this User's Guide.
Refer to the Data Silo DS550 User's Guide, Data Express DE90i-A100
or DE110 User's Guide for additional operating and installation informa-
tion. Also refer to the disk manufacturer's documentation for specific
information regarding the disks.
