Configuration 25
14. Use the ê button to enable /disable the SCSI termination for the RAID Controller, then
press Enter.
NOTE: If the RAID Controller is at the end of the SCSI bus, termination should be
enabled. If the RAID Controller is in the middle of a SCSI bus, termination
should be disabled.
15. Press ê until the 23 Tag Queuing menu is displayed, then press Enter.
16. Use the ê button to enable /disable the Tag Queuing for the RAID Controller, then
press Enter.
NOTE: The default setting for Tag Queuing is enabled. Tag Queuing allows the
RAID Controller to process multiple requests, which improve performance.
17. Press ê until the 224 Ultra and 225 Wide menus are displayed, then press Enter.
18. Refer to Table 4 to set-up the SCSI interface of the Host.
SCSI
Interface
Wide Fast Ultra Ultra2
SCSI-2
Wide SCSI
Disable
Ultra3
Ultra SCSI
Ultra Wide SCSI
Ultra2 SCSI
Ultra160 SCSI
Disable
Enable
Enable
Enable
Enable
[ENT]
[ENT]
[ENT]
[ENT]
[ENT]
[ENT]
Table 4: SCSI Set-Up
19. Press Esc to return to the Main Menu.
20. Press ê until the 5 NVRAM menu is displayed, then press Enter.
21. Press ê until the 51 Update NVRAM menu is displayed, then press Enter.
22. Press ê until the YES option is displayed, then press Enter.
23. Press ê until the 53 Restart menu is displayed, then press Enter.
24. Press ê until the YES option is displayed, then press Enter.
NOTE: This will automatically restart the RAID Controller.
