6 Introduction
StorCase Technology, Inc. DS560/DS570 User's Guide - Rev. A04
1
2
Power ON (Green)
Temperature Warning (Red)
Blower 1 or 2 Failure (Red)
Power Supply 2 Failure (Red)
Power Supply 1 Failure (Red)
Reset (Yellow)
Mute (Yellow)
Indicator and Control Panel
S_IDE04
Figure 3: Indicator and Control Panel
Figure 4A: DE90 Receiving Frame Front Panel
(Applies to DS560 model only)
• Front Panel Indicator LEDs (Figure 3A) - Indicator LEDs on the DE90i-A100
receiving frame front panel provide important operating information based on the
conditions listed in Table 1.
