20 Configuration
StorCase Technology, Inc. DS560/DS570 User's Guide - Rev. A04
Field Description
DS5X0
OOOOOOOS
Symbol Description
Model number.
Disk status. The farthest O to the left is
Disk 1. Press button to view the next
page.
X
A
O
S
R
I
Disk is not installed.
Disk is being added.
Disk is Online.
Disk is a spare disk.
Disk is removed.
Disk is being checked.
Rx
ID:x
RAID level (x = 0, 0+1, 1, 3, or 5)
configuration.
SCSI ID configuration (x=0-15).
Alternating cursor indicating operational
status.
When the Enter button is pressed in Operation Mode, the RAID Controller will go into
Configuration Mode.
NOTE: Configuration Mode will automatically cancel after 3 minutes (180 seconds) of User
inactivity.
Table 2: LCD Display Components
LEDs
Activity Indicates data is being accessed
Power Indicates power is ON
Control Panel Buttons
é Use to scroll UP through the menu items
ê Use to scroll DOWN through the menu items
ENT Use to select a menu item, open a sub-menu, or to select a a value
ESC Use to exit a sub-menu and return to the previous menu
