StorCase Technology DS570 User Manual
Page 27
18
Installation
StorCase Technology, Inc.
DS560/DS570 User's Guide - Rev. A04
Figure 12: Typical Dual Channel RAID Configuration
with Two Optional Repeaters Installed
to SCSI
Host 1
Daisy-Chain to
Another Chassis
or Terminate
VT-100/ANSI
Terminal
External
Modem
S_IDE13
to SCSI
Host 2
Daisy-Chain to
Another Chassis
or Terminate
Optional
Repeaters
