26 Configuration
StorCase Technology, Inc. DS560/DS570 User's Guide - Rev. A04
Single Host Configuration for Logical Units
A RAID array may be divided into multiple logical units. A logical unit is that portion of a disk
array seen by the host system as a single logical device. Each logical unit is identified to the
host by its Logical Unit Number (LUN). The RAID Controller can support up to eight (8) logical
units.
1. Make sure Single Host Configuration is completed first.
2. Press Enter to open the 6 RAID Funcs menu.
3. Press ê until the 62 Init R5/R3 menu is displayed, then press Enter.
4. Press ê until the STOP option is displayed, then press Enter.
5. Press Esc to return to the Main Menu.
6. Press Enter to open the 1 RAID Params menu.
7. Press ê until the 14 Slice menu is displayed, then press Enter.
NOTE: Slice will allow you to divide the partition size.
8. Press ê until the 141 Slice 0(MB) menu is displayed, then press Enter.
9. Key in the desired capacity in Slice 0, then press Enter.
10. Press ê to select the 142 Slice 1(MB) to 148 Slice 7(MB), repeat Steps 8-9.
11. Press Esc to return to the Main Menu.
12. Press ê until the 2 SCSI Params menu is displayed, then press Enter.
13. Press ê until the 216 LUN Map menu is displayed, then press Enter.
14. Press ê until the 2161 LUN 0 menu is displayed, then press Enter.
15. Refer to Table 5 to set-up LUN menu.
LUN 0
LUN 1
LUN 4
LUN 3
LUN 2
LUN 5
LUN 7
LUN 6
Slice 0
Slice 1
Slice 2
Slice 3
Slice 4
Slice 5
Slice 7
Slice 6
Table 5: LUN Set-Up
16. Press Esc to return to the Main Menu.
17. Press ê until the "5 NVRAM" menu is displayed, then press Enter.
18. Press ê until the "51 Update NVRAM" menu is displayed, then press Enter.
19. Press ê until the YES option is displayed, then press Enter.
20. Press ê until the "53 Restart" menu is displayed, then press Enter.
