WRVS4400N User Guide 27
How to Navigate the Utility
Setting Up and Configuring the Router
IPS
Use this tab for advanced configuration on built-in Intrusion Prevention System (IPS) inside the
Router.
•
Configure—Enable or disable IPS functions.
•
P2P/IM—Allows or blocks specific Peer to Peer (P2P) networks and Instant Messaging
(IM) applications.
•
Report—Provides reports of network traffic and malicious attacks.
•
Information—Provides the signature file version and the Protection Scope of the IPS
system.
L2 Switch
Use this tab to configure layer 2 switching features on the 4 port Ethernet Switch (LAN ports
only).
•
Create VLAN—Create a Virtual Local Area Network (VLAN) assignment.
•
VLAN & Port Assignment—Virtual Local Area Network (VLAN) and Port settings.
•
RADIUS—Configuration of Remote Authorization Dial-In User Service (RADIUS) settings.
•
Port Setting—Configuration of port speeds and duplex.
•
Statistics—Displays statistics for both received and transmitted packets.
•
Port Mirroring—Allows configuration of port mirroring.
•
RSTP—Used for RSTP (Rapid Spanning Tree Protocol) configuration.
Status
Use this tab to get the current status on the Router.
•
Gateway—Provides basic information like firmware version and status information on
the WAN port.
•
Local Network—Provides status information about the local network (four Ethernet
Ports).
•
Wireless LAN—Provides status information on Wireless LAN.
•
System Performance—Provides traffic statistics on LAN and Wireless LAN ports.
