WRVS4400N User Guide 13
The Front Panel
Getting to Know the Router
Getting to Know the Router
The Front Panel
The Router’s LEDs are located on the front panel of the Router.
Front of Router
Status LED/Color Description
Power/
Green
The POWER LED lights up when the Router is powered on.
The LED flashes when the Router runs a diagnostic test.
Diag/
Red
The DIAG LED lights up when the system is not ready. The
LED light goes off when the system is ready. The Diag LED
blinks during Firmware upgrades.
IPS/
Green/Red
The IPS LED lights up when the IPS function is enabled. The
LED light is off when the IPS functions are disabled. The IPS
LED flashes green when an external attack is detected. The
IPS LED flashes red when an internal attack is detected.
Wireless/
Green
The WIRELESS LED lights up when the wireless module is
enabled. The LED is off when the wireless module is disabled.
The WIRELESS LED flashes green when the data is
transmitting or receiving on the wireless module.
