The abbreviations used with the Eclipse 7 are defined below alphabetically. Related pages are given in parenthesis following the definition.

A

ACRO

Acrobatic aircraft menu (13)

ADIF

Aileron differential. Makes aileron move

more to one side than the other (32)

AIL.T

Dual aileron trim (35)

ATL

Adjustable Travel Limit. Limits throttle

trims to only the throttle idle position.

(built in to your system)

A->F

Aileron Flap mixing (35)

A->R

Aileron Rudder mixing (24)

C

camber A function which droops or raises the

entire trailing edge of a glider wing.

COPY

Data copy: command used to copy one

memory to another (10)

CROW Airbrake function for gliders
CURSOR Button used to step through menus (8)

D

D/R

Dual rate: switch-controlled function

reduces control travels. (18)

DATA

Editing keys change numbers (8)

DFL.T

Dual Flap trim knob (36)

E

ELVN

Elevon function combines ailerons &

elevators for tailless models. (24)

EPA

End Point Adjust. Function that adjusts the

servo travel at the left and right sides. (24)

EXP

Exponential function, used to reduce

sensitivity around neutral (20)

E->F

Elevator Flap mixing (23)

F

FLPN Flaperon function gives the ailerons

a flap function. (26)

FLT.C Flight condition function (20)
FLPT

Flap trim function; controls flap neutral

position. (23)

F->A

Flap Aileron mixing (33)

F->E

Flap Elevator mixing (33)

G

Gear Landing gear control switch. (7)
GLID Glider settings menu (28)
GYRO Gyro setting menu (42)

H

HELI

Helicopter settings menu. (10)

HOLD Throttle hold function holds the throttle in a

near-idle position (used for autorotation). (42)

I

INH

Inhibit. Function will not operate

L

L/U

Indicator showing Left or Up stick motion

LAND Landing function (23)
Lock

Lock throttle button (9)

M

MAS Master channel in mixer (22)
M.SEL Model select menu (10)

N

NOR Normal helicopter swashplate (1 servo each

for elevator, aileron, pitch. (10)

O

OFF

Function or Switch in OFF position.

ON

Function or Switch in ON position.

P

PMX

Programmable mixer. Mixing between

arbitrary channels. (22)

PTCV Pitch curve function (43)

R

R/D

Indicator showing Right or Down stick motion

REV

Reverse. Servo operating direction switching

function. (22)

REST Reset model memory (12)
RVMX Revolution mixing (44)
R->T

Rudder Throttle mixing (42)

S

SLV

Slave channel in program mixer (22)

ST1, ST2, ST3 Flight condition 1, 2, & 3 indicators
STM.1,2 Speed Flap Trim offsets 1 & 2 for gliders

(launch presets, etc.) (35)

S.TRM Subtrim function used to adjust servo neutrals.

(21)

SWAH Swash type (10)

T

T.CUT Throttle cut function used to kill engine without

moving trims (22)

THCV Throttle curve function (43)
TIME Timer/Stopwatch function (12)

V

VTAL V-tail function combines the elevators and

rudder. (25)

Numerical

120'

Helicopter swashplate, 120 deg. (10)

180'

Helicopter swashplate, 180 deg. (10)

2WNG Glider with 2 wing servos (10)
4WNG Glider with 4 wing servos (10)

Model Name ___ ___ ___ ___ -__ __ __

Memory No. 1 . 2 . 3 . 4 . 5 . 6 . 7

PMX1 Programmable Mixer 1

ON . INH

MAS CH ___ SLV CH ___ R/D + . - __% L/U + . - __%

PMX2 Programmable Mixer 2

ON . INH

MAS CH ___ SLV CH ___ R/D + . - __% L/U + . - __%

PMX3 Programmable Mixer 3

ON . INH

MAS CH ___ SLV CH ___ R/D + . - __% L/U + . - __%

PMX4 Programmable Mixer 4

ON . INH

MAS CH ___ SLV CH ___ R/D + . - __% L/U + . - __%

PMX5 Programmable Mixer 5

ON . INH

MAS CH ___ SLV CH ___ R/D + . - __% L/U + . - __%

LAND Landing Mixing

ON . INH

CH2 ____% CH6 ____%

FLPT Flap Trim

ON . INH

Amount ____%

E->F Elevator Flap Mixing

ON . INH

Up ____% Down ____%

A->R Ail Rud Mixing

ON . INH

Left ____% Right ____%

ELVN Elevon Mixing

ON . INH

2-2 ____% 2-1 ____% 1-1 ____% 1-2 ____%

VTAL V-tail Mixing

ON . INH

2-2 ____% 2-4 ____% 4-4 ____% 4-2 ____%

FLPN Flaperon Mixing

ON . INH

1-1 R ____% 1-1 L ____% 1-6 R ____% 1-6 L ____% 6-6 ____% 6-1 ____%

MENU FUNCTION

CH 1

CH 2

CH 3

CH 4

CH 5

CH 6

CH7

REV Servo Rev (circle)

N . R

N . R

N . R

N . R

N . R

N . R

N . R

EPA End Point Adj. R/D

%

%

%

%

%

%

%

L/U

%

%

%

%

%

%

%

SBTR Subtrims Value

%

%

%

%

%

%

%

D/R

NOR

Up

%

%

%

Down

%

%

%

D/R

ST1

Up

%

%

%

Down

%

%

%

D/R

ST2

Up

%

%

%

Down

%

%

%

D/R

ST3

Up

%

%

%

Down

%

%

%

EXP NOR

Up

%

%

Down

%

%

EXP ST1

Up

%

%

Down

%

%

EXP ST2

Up

%

%

Down

%

%

EXP ST3

Up

%

%

Down

%

%

T.CUT

%

ACRO Model Data Recording Sheet

Make copies before using

GLOSSARY
