3
Model Setup Functions
Introduction to the Eclipse 7 System
Congratulations! You now own a Hitec Eclipse 7, an extremely versatile R/C system that may be effectively used by
both beginning and master pilots. The transmitter may be programmed for airplanes, gliders, or helicopters, all with
special mixing functions, so it can accommodate virtually any model configuration. You can store programming for
seven different models in this powerful system! The transmitter will remember all of your settings for each of your
different models forever - no backup battery is ever needed. With programmable shift, it can be used with all PPM/FM
receiver models, even other brands!
The system pushbuttons allow rapid data input into the easy-to-read LCD display. With its electronic digital trims,
you'll never lose your trim positions again, because they stay at the same place you left them!
Standard programming features include servo reversing for all channels, end point adjust on all channels, dual rates,
and exponential. Pre-programmed functions and programmable mixers allow you to use the system for any type of
model you can imagine. For those learning to fly, the transmitter has "buddy-box" capability (a second transmitter
may be connected for training by an instructor pilot with an optional trainer cord). The Eclipse 7 menus even have the
advanced "flight condition" settings found in other radios costing hundreds of dollars more in all its menus!!
The extensive preprogrammed mixing features for aircraft include flaperon (dual aileron servos), V-tail, elevon (for
flying-wing models), landing settings, throttle cut, aileron rudder mixing, and elevator flap. Five programmable
mixers for custom functions are also provided.
For sailplanes, you find the following custom programming for competition and sport models with two or four wing
servos: crow mixing for spot landings, flap aileron mixing, aileron flap, elevator flap, aileron rudder,
flap elevator, two sets of switchable offsets for launching and speed, V-tail, aileron differential, and five
programmable mixers. The second aileron is on channel 5, so you can use the system with ultralight five-channel
receivers without any problems!
Helicopter features include five-point pitch and throttle curves, high and low revolution mixing, throttle cut, throttle
hold, gyro settings, and rudder throttle mixing. You may select a conventional swashplate, or if you have a more
complex chopper, mixing is provided for two types of three-servo swashplates.
About this manual
This manual is not just a translation - it has been carefully written from scratch to be as helpful to you, the new owner,
as possible. There are many pages of setup procedures, examples, explanations, and trimming instructions. In order
for you to make the best use of your system and to fly safely, please read this manual carefully. If you don't have time
to read it thoroughly, at least spend some time browsing through it to see all the features this fine system has to offer.
Eclipse 7 System Options:
1. Airplane Version, Item #171721. Includes four HS-422 deluxe servos, 8 channel Supreme receiver, 600 mAH
airborne battery, standard switch harness, 12" (30 cm) servo extension cord and overnight wall charger.
2. Airplane Spectra Version, Item #171723. Includes four HS-425BB ball-bearing servos, Spectra programmable
frequency module, 8 channel Super Slim receiver, 600 mAH receiver battery, heavy-duty switch, 12" (30 cm) servo
extension cord and overnight wall charger.
3. Helicopter Version, Item #171725. Includes five HS-425BB ball-bearing servos, 8-channel Supreme receiver,
1000 mAH receiver battery, heavy-duty switch harness and overnight wall charger.
These versions come with the following accessories:
Frequency number flag
Hardware and mounting package for all the servos
Additional "smooth click" throttle ratchet
"Flight preserver" closed-cell foam wrap to protect the receiver from shock and vibration.
Warranty card
Manual
4. Eclipse Transmitter only, with Spectra module, Item #171724.
Eclipse transmitter with Spectra Synthesizer Module, manual, overnight wall charger, and warranty card.
This product is to be used for sport and recreational flying of radio-control models only. Hitec is not responsible
for the results of use of this product by the customer or for any alteration of this product, including modification or
incorporation into other devices by third parties. Modification will void any warranty and is done at owner's risk.
If you have any difficulties, please consult this manual, your hobby dealer, or Hitec (contact information is provided
in the rear of this manual). Note the information contained in this manual is subject to change without notice due to
possible changes in manufacturing procedures, system software programming, or updates.
"Hitec" is a registered trademark of the Hitec RCD, Inc.
Disclaimer: This information specific to North American versions of the Eclipse.
