Page 44
FY-41AP-OSD INSTRUCTIONS
(i) The FY41AP has an integrated OSD video overlay hardware built
into the system.
(ii) This allows the FY-41AP to display critical flight telemetry
information onto your existing video downlink without the need for
an external OSD Module.
(iii) The FY-41AP-OSD can adapt to both PAL & NTSC video signal.
WORKING PROCEDURE
(i) After power ON, the OSD will immediately activate.
(ii) If there is no video input, the OSD will only display the FY LOGO and
wait for the incoming video input.
(iii) After the video stream is transmitted, even when there is a break in
camera video signal output, the FY-41AP OSD will continue
transmitting telemetry information via the video transmitter.
FLIGHT MODE ABBREVIATION
Flight Mode
Abbreviation
Introduction
RC Manual Flight. Autopilot deactivated.
3D 3D Mode
ABM Auto balance mode
NAV Preset Path & Point Navigation Flight Mode
RTL Auto Return to Launch Mode
ADH Fixed altitude & Heading lock flight Mode
ACM Auto Circling Mode
