Page 35
Centre is at point of ACM activation.
Path
Preset Path & Point
Navigation Flight Mode
Airplane will fly autonomous, following
waypoints set via FY-GCS. Requires
FY-Data Radio to save Waypoint to
FY41AP module.
(16) Reverse - Reversing Servo in Stabilized Mode
(i) If in ABM, the automatic servo action is incorrect (reversed), use
this to reverse the servo direction.
(ii) You can reverse the automatic (ABM) stabilized servo direction for
any of the listed channels (AIL, ELE, THR, RUD).
(iii) Press „Set‟ to confirm and save the direction reversal.
(iv) Check that the direction has been corrected after disconnecting the
FY41AP from the PC.
(17) Circling Radius Setting
(i) The FY41AP can fly over a set GPS point upon activation of Auto
Circling Mode via switch SW-2.
(ii) The default circling radius is 80 meters.
(iii) You may adjust this circling radius using this Setting Software
function. Press „Set‟ to confirm and save your updated
circling radius.
(18) DIALOG BOX
(i) A dialog box is located at the bottom of the Setting Software.
(ii) This dialog box confirms any setting updates carried out by you.
