INTEGRATED CURRENT SENSOR / POWER MANAGER
a) The FY-41AP is supplied with a Power Manager that is both a current sensor
& supply.
b) The module outputs +5v to supply to the FY41AP and RC Receiver. It also
supplies regulated +12v to power the video transmitter and FPV camera.
c) We DO NOT recommend using the internal BEC of your ESC to power the
FY41AP as this is unregulated power.
The 5-female plug from the Power
Manager sends +5V to power the
FY41AP & RC Receiver. It also powers
your +12v FPV Camera and Video
transmitter. The green & yellow plugs
send current sensor data.
