GPS INSTALLATION AND REQUIREMENTS
a) Install the GPS Module on the airplane with the antenna face up:
b) DO NOT install next to metal or carbon fiber & other shielding material,
which may block satellite signal reception.
c) Install the GPS Module away from electromagnetic sources such as ESC‟s,
power wires, servo wires & video transmitters which can interfere with GPS
signal.
d) Wire interface:
Color
Black
Red
White
Function
GND
+5v
GPS Data
e) Note that the FY41AP utilizes only the 5 volt version of the FY GPS Module.
Face Upwards
