FeiYu Tech FY-41AP - Manual (Page 24)

GuiLin FeiYu Electronic Technology Co., Ltd. http://www.feiyudz.cn E-mail: [email protected]
Page 23
FY-41AP INSTALLATION POSITION
a) When installing the FY41AP, please install it horizontal & as close as possible
to the "Centre of gravity" (COG) of the aircraft.
b) A module that is not installed horizontal can result in stabilization issues as
below:
c) However, minor flight deviation due to non-horizontal installation can be
corrected with using your RC Transmitter trims.
Plane roll remains level when in Auto Stabilization Mode
FY-41A
P
Plane will roll to
the right when in
Stabilized Mode
Plane will roll to
the left when in
Stabilized Mode
FY-41A
P
FY-41A
P
Plane pitch remains level when
in Auto Stabilization Mode
FY-41A
P
Plane nose will pitch down when
in Auto Stabilization Mode. Plane nose pitches up when
in Auto Stabilization Mode.
FY-41A
P
FY-41A
P
