Setting up and Using the Optical Sampling Oscilloscope
80 PSO-100
Saving Sample Files
4. Click Save / print.
5. Select to save the file to the desired folder, or to print it.
To save the sample as data:
1. From the main window, select File, then Save data.
2. Under the Save setup menu, select if you want to include the
waveform samples for channel A and/or B for the top and bottom
window
Note: If you are not using the dual window setting, or if only channel A or B are
active, you will have fewer choices.
3. Click Save. Confirm the location and format for the resulting file (.csv
for Excel format, or .mat for Matlab format).
