Broadband Source 85
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS a
Single SLED
Parameter FLS-2200-06 c FLS-2200-02 FLS-2200-05 FLS-2200-03 FLS-2200-04
Center wavelength (nm) 980 ± 10 1300 ± 20 1485 ± 15 1550 ± 20 1610 ± 15
3 dB spectral width (nm) * 20 (25 typ.) * 40 (45 typ.) * 50 (60 typ.) * 50 (56 typ.) * 50 (55 typ.)
Output power (dBm) 0 4 –3.5 5 5
Minimum spectral density (dBm/nm) b –18 (970-990 nm) –25 (1260-1360 nm) –27 (1450-1510 nm) –27 (1510-1590 nm) –20 (1565-1640 nm)
Peak spectral density (dBm/nm) b –13 –12 –21 –9 –10
Total power stability (dB) d
15 min
8 hours ± 0.01
± 0.01 ± 0.01
± 0.01 ± 0.01
± 0.01 ± 0.01
± 0.01 ± 0.01
± 0.01
Spectral density stability (dB) b, d, e
15 min
8 hours ± 0.01
± 0.015 ± 0.01
± 0.015 ± 0.01
± 0.015 ± 0.01
± 0.015 ± 0.01
± 0.015
Ripple (dB) e, g 0.3 0.3 0.3 0.3 0.3
Fiber type (μm) 5/125 9/125 9/125 9/125 9/125
Dual SLED
Parameter FLS-2200-23 FLS-2200-SCL
Center wavelength (nm) 1300 ± 20/1550 ± 20 1485 ± 15/1570 ± 10
Output power (dBm) f * 8 * –3.5
Minimum spectral density (dBm/nm) b
–28 (1260-1360,
1510-1590 nm)
–29 (1460-1625 nm)
Peak spectral density (dBm/nm) b –10 –23
Total power stability (dB) d
15 min
8 hours ± 0.01
± 0.015 ± 0.01
± 0.015
Spectral density stability (dB) b, d, e
15 min
8 hours ± 0.01
± 0.01 ± 0.01
± 0.01
Ripple (dB) e, g 0.3 0.3
Fiber type (μm) 9/125 9/125
Notes
a. Specifications are valid at 23 °C ± 2 °C, at maximum power after warmup time
(30 minutes), with isolator, for return loss of
* 30 dB.
b. Typical value.
c. Specifications for the 980 nm source are set without an isolator.
d. Stability is expressed as ± half the difference between the maximum and minimum
values measured in the period.
e. Measured in a 0.1 nm resolution bandwidth.
f. Output power of dual SLED source is the sum of the power output of each
individual SLED.
g. The ripple is specified over a spectral range limited to 3 dB below the peak
power density.
GENERAL SPECIFICATIONS
Size (H x W x D) 117 mm x 222 mm x 333 mm
(4
5 / 8 in x 8 ¾ in x 13 1 / 8 in)
Weight b 2.7 kg (5.9 lb)
Temperature
operating
storage 0 o C to 40 o C (32 o F to 104 o F)
–40 o C to 70 o C (–40 o F to 158 o F)
Relative humidity 0 % to 80 % non-condensing
SAFETY
IEC 60825-1:A2: 2001
Class 1M LED Product
