Preparing for Remote Control
Broadband Source 31
Setting GPIB Address
Setting GPIB Address
If GPIB is selected as the remote command mode, you can select the GPIB
address you want to use from 1 to 30 (default value is 12).
To set a GPIB address:
1. Press the Setup button.
2. Use the up/down or left/right arrow keys to select GPIB Addr. The
current GPIB address is displayed.
Note: If you are in RS-232 mode, the GPIB address cell will display “N.A.” You
must change the communication mode to GPIB before setting an address.
3. Press ENTER, then use the up/down arrow keys to select a GPIB
address between 1 and 30.
4. Press ENTER to confirm your choice.
Refresh Rate
Backlight
Contrast
Video Mode
Exit
8 Hz
ON
STD
RS232 / GPIB
GPIB Addr.
Baud Rate
Flow Ctrl
GPIB
12
N.A.
N.A.
