Broadband Source

Setting Up Your Broadband

Source

The blue button on the right of the display provides access to the
single-level Setup menu. You can access this menu even while the source
is active to set up the various parameters.

Setting the Refresh Rate

To set the refresh rate:
1. Press the Setup button.

2. Use the up/down or left/right arrow keys to select Refresh Rate (the

item will be displayed in reverse video).

3. Press ENTER to access the Refresh Rate edit box.

4. Use the up/down arrow keys to set the refresh rate between 1/2 Hz,

1 Hz, 2 Hz, 4 Hz, 8 Hz and 16 Hz.

5. Press ENTER to confirm the new refresh rate.

Refresh Rate

Backlight

Contrast

Video Mode

8 Hz

STD

Exit

RS232 / GPIB

GPIB Addr.

Baud Rate

Flow Ctrl

GPIB

N.A.
