Setting Up Your Broadband Source
Broadband Source 19
Setting the Video Mode
Setting the Video Mode
To set the video mode:
1. Press the Setup button.
2. Use the up/down or left/right arrow keys to select Video Mode (item
will appear in reverse video).
3. Press ENTER to access the Video Mode edit box.
4. Use the up/down arrow keys to set the required video mode (standard
or reverse).
5. Press ENTER to confirm the video mode.
Refresh Rate
Backlight
Contrast
Video Mode
Exit
8 Hz
ON
STD
RS232 / GPIB
GPIB Addr.
Baud Rate
Flow Ctrl
GPIB
12
N.A.
N.A.
Refresh Rate
Backlight
Contrast
Video Mode
Exit
ON
INV
RS232 / GPIB
GPIB Addr.
Flow Ctrl
GPIB
12
N.A.
N.A. Baud Rate
Exit
8 Hz
Baud Rate
